IVO M140NW4D R4 14" LCD Panel PC LCD Module with 1920x1200 Resolution 300cd/m2 Brightness and 15k Hours Working Time

  • 1
  • 2
  • 3

Brand Name : IVO

Model Number : M140NW4D R4

Certification : Rohs,CE,FCC

Place of Origin : korea

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W,Western Union,MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

material : glass oled

color : 16.7M colors

model : XGA

style : wide screen high resolution 1920*1200Pixels

brightness : 300cd

connector : ePD 2 lanes

contrast ratio : 1000:1

working time : 15k hours

Contact Now

IVO M140NW4D R4 14" 1920*1200 LCD Panel
High-performance 14-inch desktop LCD panel with WUXGA resolution, 16.7 million colors, and 300 cd/m² brightness. Designed for laptop applications with 15,000 hours LED backlight lifespan.
Product Overview
The M140NW4D R4 is a 14.0" diagonal a-Si TFT-LCD display panel from InfoVision Optoelectronics featuring an integral WLED backlight system with LED driver. This panel operates within 0~50°C and offers excellent viewing angles with IPS technology.
IVO M140NW4D R4 14" LCD Panel PC LCD Module with 1920x1200 Resolution 300cd/m2 Brightness and 15k Hours Working Time
Key Specifications
BrandIVO
Model P/NM140NW4D R4
Diagonal Size14.0"
Panel Typea-Si TFT-LCD, LCM
Resolution1920(RGB)*1200 (WUXGA), 161 PPI
Active Area301.594(W)*188.496(H) mm
Luminance300 cd/m² (Typical)
Contrast Ratio1000:1 (Typical)
Viewing Angle89/89/89/89 (CR≥10) Left/Right/Up/Down
Color Depth16.7M colors, 45% NTSC
Response Time20 ms (Typical, Tr+Td)
Refresh Rate60Hz standard, up to 240Hz with MEMC
BacklightWLED, 15K hours, With LED Driver
Signal TypeeDP (2 Lanes)
Voltage Supply3.3V (Typical)
Operating Temperature0 ~ 50°C
Storage Temperature-20 ~ 60°C
Outline Dimensions306.59(W)*198.9(H)*5.1(D) mm
Advanced Features
  • IPS Family Technology (AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich)
  • Multiple Refresh Rate Options: 60Hz, 120Hz (with MEMC), 240Hz (with MEMC)
  • Slim design with PCBA Bent (T≤3.0mm)
  • Normally Black, Transmissive work mode
  • RGB Vertical Stripe pixel format
Application
Primarily designed for laptop integration. This module does not include touch screen capability.
Note: Production status information is for reference only. For the latest production and specification details, please contact IVO or their authorized agents before making integration decisions.
